FUNCTIONAL PRINCIPLE OF RADIO SENSORS SENDER unitS

AMF RADIO SENSÜRS -WiRELESS COMMÜNiCATiON TECHNOLOGY FOR YOÜR PRODUCTiON Radio pressure switch Sender unit

Whether in clamping technology or for modern handling and storage systems - the AMF radio sensor is the perfect solution for a fully automated, unmanned production process. Wireless signal transmission by means of failure-free Bluetooth Low Energy 4.0, very long battery life as well as space-saving small construction are just a few features of this innovative technology. Inexpensive to buy and flexible to use, the AMF radio sensor ensures seamless process integration and thus increases the efficiency in your production. Sender unit, longlife Subject to technical alterations.

With the reed switch the position of the cylinder piston is scanned in the clamping element and transmitted by the connected sender unit wirelessly to the gateway. Integrated support control by built-in microswitches in the fixture. Once the workpiece is mounted, the release is transmitted wirelessly to the gateway and machine control via the sender unit.

Hydraulic pressure monitoring by means of the integrated radio pressure switch. This monitors in this case the system pressure of the hydraulic zero point clamping station. The gateway is connected to the machine control. A WLAN router can be connected optionally to access the web-based user interface of the gateway via a tablet. Subject to technical alterations.

Amp(i> Gateway Design: Inputs: 8 wireless with transmission protocol Bluetooth Low Energy (BLE 4.0), transmission frequency 2.4 GHz. Outputs: 8 potential-free relay outputs, electrlcally ¡solated, with screw termináis. Max. 60W / 125VA - 220 VDC / 250 VAC, 2A Radio slgnal range to the sender unlt ¡s approx. 10 metres. An extensión of the radio slgnal ¡s posslble with antenna extensión. Power supply voltage: 24 V DC, nominal current 0.2 A Deslgned for amblent temperatures from +5 to +65 ,:,C. Application: Gateway (recelver) for wireless communlcatlon between sender unlts and the machine control....

Amp(l> Sender unit Design: The sender units are available in two versions. The longlife sender unit with Order No. 554179 has a battery life of up to 5 years and differs from the standard version in energy management (number and version of batteries) with a battery life of up to 1.5 years. Input: 1 cabled input for the sensors. Output: 1 wireless - to the gateway. Radio signal range to the gateway is approx. 10 metres. Designed for ambient temperatures from +5 to +65 °C. Application: Sender unit for wireless communication between sensors and the gateway. The sensor (sensor system) is connected...

Amp(i> Radio pressure switch Design: The radio pressure switches are available in two versions with different pressure ranges. Output: 1 wireless - to the gateway Sensor type: Mechanical pressure switch Radio signal range to the gateway is approx. 10 metres. Application: Wireless pressure switch for pressure monitoring of a hydraulic clamping circuit on machine tables, fixtures, in workpiece storage technology and other storage systems. The integrated sender unit transmits the switching state to the gateway via Bluetooth Low Energy (BLE 4.0). Note: Other pressure ranges available on request....

Subject to technical alterations.

Amp(i> Sensors Design: Reed switch with plástic housing. Function: PNP. See specification for length of connection cable, the connector (M8) is preassembled ready for connection for the AMF sender unit. Designed for ambient temperatures from -25 to +70 °C. Application: The reed switch (cylinder sensor) for T-slot cylinders signals the position of the piston, for example. It detects a ring magnet in the cylinder piston when it passes the position of the sensor and signals this via a switch signal. Can be used on all standard cylinders made of non-magnetisable material. The IP67-certified switch...

Amp(l> Sensors Amp(l> Sensors Microswitch, plástic housing Design: Microswitch with plástic housing. Function: PNP with mechanical contact. See specification for length of connection cable, the connector (M8) is preassembled ready for connection for the AMF sender unit. The stroke is a max. of 2.7 mm with an operating force of 1.2 N. Designed for ambient temperatures from 0 to +80 °C. Application: With their compact design, these microswitches are suitable, for example, as grip control for robot grippers or in detector applications. The mini stroke pushbutton has been designed for contact reliability...

Amp(i> Sensors Design: Microswitch with V2A housing M10x0.75 and hardened striking surface, flush mountable. Function: PNP with mechanical contact. See specification for length of connection cable, the connector (M8) is preassembled ready for connection for the AMF sender unit. The stroke is a max. of 0.5 mm with an operating force of 0.8 N. The static load of the probe tip (stain-less steel ball) is a max. of 1500 N. Designed for ambient temperatures from 0 to +80 °C. Application: With their compact design, these microswitches are suitable, for example, as grip control for robot grippers or...
